Wagner Tuning 2012+ Audi RS3 8V/2014+ Audi TTRS 8S EVO1 Competition Intercooler Kit

2012+ Audi RS3 8V/2014+ Audi TTRS 8S EVO1 Competition Intercooler Kit from Wagner Tuning.

An intercooler removes heat from the compressed charge air before it reaches the engine. Cooler air is denser and holds intake temperatures steadier through repeated hard runs. Core volume sets how much heat the cooler can absorb, while flow area and end-tank shape decide how much pressure is lost across it. Wagner Tuning lists a 660 x 180 x 110 mm core with 13.07 liters (+57% vs. the factory 8.3 liters) and a flow area of 1,188 cm² (+14% vs. OEM 1,043 cm²). These are Wagner's own comparisons with the factory intercooler; they describe cooling capacity and are not a power figure.

Specifications

• Core: 660 x 180 x 110 mm
• Volume: 13.07 liters (+57% vs. the factory 8.3 liters)
• Flow area: 1,188 cm² (+14% vs. OEM 1,043 cm²)
• Pressure resistance: up to 6 bar
• Weight: 8.3 kg
• Installation: direct replacement for the factory intercooler (plug-and-play per Wagner)

Wagner lists this for

• Audi RS3 8V Sportback, 270 kW/367 hp, 04/2015-04/2016
• Audi RS3 8V Sportback/Sedan, 294 kW/400 hp, from 08/2017
• Audi RS3 8Y Sportback/Sedan, 294 kW/400 hp, from 2021
• Audi TT RS 8S, 294 kW/400 hp, from 11/2016
• Audi RS Q3 F3, 294 kW/400 hp, from 10/2019

What is in the kit

• Intercooler (black coated)
• Mounting material
• Installation instructions

Before you order

• ORT does not quote horsepower or temperature gains for this part; results depend on the car, tune and conditions.
• Confirm model, engine and year against the fit table before ordering.
